Using JRiver convolver for external sources

Ofer

New Member
Thread Starter
Joined
Mar 15, 2021
Messages
109
My AV System
Preamp, Processor or Receiver
miniDSP 4x10hd
Main Amp
Emotiva XPR200 midrange amp
Additional Amp
Crest audio 2001A bass amp
Other Amp
Rotel RA930ax twitter amp
Computer Audio
Sony Bravia android TV
DAC
miniDSP 4*10HD
Front Speakers
Andromeda MkII
Screen
Sony bravia 65XF9005
Streaming Subscriptions
Deezer HiFi
Other Equipment
Marantz original 5E CD
Hi everyone,
My attempts to use AL standalone convolver for playing external spdif source have been futile (see my post baby steps with AL). I was wondering if there is anyone who tried using JRiver convoler with an external source pluged to the soundcard? preferably with an RME card.


jjazdk

Member
Joined
Aug 17, 2018
Messages
74
I have used the JRiver convolver with external sources, with an Atlas Sound card and with a Scarlett as well. So, yes, that does work.


Ofer

New Member
Thread Starter
Joined
Mar 15, 2021
Messages
109
My AV System
Preamp, Processor or Receiver
miniDSP 4x10hd
Main Amp
Emotiva XPR200 midrange amp
Additional Amp
Crest audio 2001A bass amp
Other Amp
Rotel RA930ax twitter amp
Computer Audio
Sony Bravia android TV
DAC
miniDSP 4*10HD
Front Speakers
Andromeda MkII
Screen
Sony bravia 65XF9005
Streaming Subscriptions
Deezer HiFi
Other Equipment
Marantz original 5E CD
Thanks, is switching between filters a streamline process? can you assign presets or something like that? or is it basic file menu open file etc.


jrobbins50

Member
Joined
Oct 4, 2018
Messages
128
Thanks, is switching between filters a streamline process? can you assign presets or something like that? or is it basic file menu open file etc.
I’ve been over to listen to the new all Wilson 7.1.4 system that Chris Connaker of audiophilestyle.com has put together. He runs his AL filters created by Mitch through JRiver. I did notice that he manually was changing the filter set when moving from 24/48 Atmos files to 24/96 and 24/192 standard MCH files. This may mean that there is not a preset system in JRiver. @Mitchco can likely confirm. JCR

Joined
Apr 25, 2017
Messages
75
Location
Omaha, NE
My AV System
Preamp, Processor or Receiver
StormAudio ISP.32 AVB
Main Amp
Digital Amp Company Cherry MEGASchino MONO's
Additional Amp
Digital Amp Company Cherry Maraschino's
Universal / Blu-ray / CD Player
HTPC
Front Speakers
JTR Speakers Noesis 215RM
Center Channel Speaker
JTR Speakers Noesis 215RM
Surround Speakers
JTR Speakers Slant 8
Surround Back Speakers
JTR Speakers Slant 8
Front Height Speakers
JTR Speakers Slant 8
Rear Height Speakers
JTR Speakers Slant 8
Subwoofers
4 ea JTR Speakers Captivator S2's
Other Speakers or Equipment
Infinite Baffle - 8 Acoustic Elegance IB15 drivers
Video Display Device
JVC DLA-NX7
Screen
Seymour AV Retractable CenterStage XD
JRiver can automatically switch filters for sample rates.



jrobbins50

Member
Joined
Oct 4, 2018
Messages
128
Ok, Chris confirms the above and clarified his issue with me:

Sample rate switches are easy, but channel configuration switches are hard.

For example,

A 5.1 album has speakers numbered 1 = Front Left, 2 = Front Right, Center = 3, LFE = 4, Rear Left = 5, Rear Right = 6
A 4.0 album has speakers numbered 1 = Front Left, 2 = Front Right, 3 = Rear Left, 4 = Rear Right

Without any channel mapping that changes based on the number of channels being played, the 4.0 track will play the front right and left just fine, but the rear left will go to the center channel and the rear right will go to the LFE. It’ll just play to the first four channels.

I don’t believe JRiver can auto select both the sample rate and number of channels. I could be wrong though.”

But, back to the original topic. JCR


Ofer

New Member
Thread Starter
Joined
Mar 15, 2021
Messages
109
My AV System
Preamp, Processor or Receiver
miniDSP 4x10hd
Main Amp
Emotiva XPR200 midrange amp
Additional Amp
Crest audio 2001A bass amp
Other Amp
Rotel RA930ax twitter amp
Computer Audio
Sony Bravia android TV
DAC
miniDSP 4*10HD
Front Speakers
Andromeda MkII
Screen
Sony bravia 65XF9005
Streaming Subscriptions
Deezer HiFi
Other Equipment
Marantz original 5E CD
OK thanks. I have never used JRiver. Can someone explain how to configure it for use of external source through the convolver?


Kal Rubinson

Active Member
Joined
Nov 6, 2017
Messages
231
Location
NYC / CT
I don’t believe JRiver can auto select both the sample rate and number of channels. I could be wrong though.”
Yes, it does. Just set Output Format -> Channels to the system config (and not Output Formatting). Mine is set right now to 5.1 channels and I am playing a 4.0 channel source via a VST3 5.1 plug-in with all channels mapped properly.


Ofer

New Member
Thread Starter
Joined
Mar 15, 2021
Messages
109
My AV System
Preamp, Processor or Receiver
miniDSP 4x10hd
Main Amp
Emotiva XPR200 midrange amp
Additional Amp
Crest audio 2001A bass amp
Other Amp
Rotel RA930ax twitter amp
Computer Audio
Sony Bravia android TV
DAC
miniDSP 4*10HD
Front Speakers
Andromeda MkII
Screen
Sony bravia 65XF9005
Streaming Subscriptions
Deezer HiFi
Other Equipment
Marantz original 5E CD
Yes, it does. Just set Output Format -> Channels to the system config (and not Output Formatting). Mine is set right now to 5.1 channels and I am playing a 4.0 channel source via a VST3 5.1 plug-in with all channels mapped properly.
So if I use a 3way active xover with sub. Totaling 7 channels with AL I should opt for 5.2 is JRiver? And downmix to 2.1 or 2 as this is a stereo setup?


Kal Rubinson

Active Member
Joined
Nov 6, 2017
Messages
231
Location
NYC / CT
So if I use a 3way active xover with sub. Totaling 7 channels with AL I should opt for 5.2 is JRiver? And downmix to 2.1 or 2 as this is a stereo setup?
Oh. I was not thinking of active multiamping. The answer will depend on where/how in the signal path you are doing the c/o. Frankly, I have very little experience with that.


Ofer

New Member
Thread Starter
Joined
Mar 15, 2021
Messages
109
My AV System
Preamp, Processor or Receiver
miniDSP 4x10hd
Main Amp
Emotiva XPR200 midrange amp
Additional Amp
Crest audio 2001A bass amp
Other Amp
Rotel RA930ax twitter amp
Computer Audio
Sony Bravia android TV
DAC
miniDSP 4*10HD
Front Speakers
Andromeda MkII
Screen
Sony bravia 65XF9005
Streaming Subscriptions
Deezer HiFi
Other Equipment
Marantz original 5E CD
Can anyone please explain how to configure JRiver to play from spdif source through the convoler? What are the steps one needs to take?
Another thing, when configured to use external sources does JRiver become like a "preamp" i.e. can you choose a source manually or does it changes automatically?

Last edited:

juicehifi

Audiolense
Staff member
Joined
Feb 5, 2018
Messages
454
So if I use a 3way active xover with sub. Totaling 7 channels with AL I should opt for 5.2 is JRiver? And downmix to 2.1 or 2 as this is a stereo setup?
5.2 in jriver and silence in unused channels.
