Negatrons IIs final rack

NBPK402

Moderator
Staff member
VIP Supporter
Thread Starter
Joined
Apr 17, 2017
Posts
1,784
Location
San Miguel de Allende Mexico
I am making a new Audio Equipment cabinet out of 1" Perota wood. The new cabinet will be about 6'w x 4'h x2'd. I am trying to make the rack to were it looks like a solid piece of artwork with access points hidden. The cabinet will have exposed screws screws in the top and bottom and possibly on the sides too. Inside of the cabinet will be my custom Perota rack.The slats will be attached to a wood frame with black speaker grill sandwiched between the 2. I am still debating on doing the slats on all for sides, just on the front, or front and sides. IThe rack will have shelves that are resting on a the steel shelves i have already had made and painted, and will be held together by round Perota wood columns. the whole internal rack will be attached to the top and bottom panels at the same locations as the columns and also via the side panels. Similar to the pics below... The completed metal shelf is also shown. The whole rack will be can be easily disassembled for moving too. I am thinking of making the 3' wide x 4' high doors with the hinges behind the grill cloth frame and use some magnets to make sure the whole assembly stays flush when closed. Sometime this week the basic rack part should be completed. Comments, suggestions all welcome..



front panel.jpg
hidden access.jpg
Perota wood.jpg
rack painted.jpeg

Last edited:

Wayne A. Pflughaupt

Moderator
Staff member
Joined
May 21, 2017
Posts
681
Location
Corpus Christi, TX
More
Preamp, Processor or Receiver
Yamaha CX-A5000 A/V Preamp / Processor
Main Amp
Yamaha RX-Z9 AV Receiver (as multichannel amp)
Universal / Blu-ray / CD Player
Denon DCT-3313 UDCI Universal Disc Player
Streaming Equipment
Roku Express
Front Speakers
Canton Karat 920
Front Wide Speakers
Realistic Minimus 7 (front EFX speakers)
Center Channel Speaker
Canton Karat 920
Surround Speakers
Canton Plus D
Surround Back Speakers
Yamaha YDP2006 Digital Parametric EQ (front mains)
Front Height Speakers
Yamaha YDP2006 Digital Parametric EQ (surrounds)
Rear Height Speakers
Yamaha YDP2006 Digital Parametric EQ (sub)
Subwoofers
Hsu ULS-15 MKII
Other Speakers
Adcom ACE-515 (for power management)
Screen
Pioneer PDP-6010FD 60" Plasma TV
Video Display Device
Yamaha DT-2 (digital clock display)
Remote Control
Stock Yamaha Remote
Other Equipment
Audio Control R130 Real Time Analyzer
Wow, that looks pretty neat! Keep posting updates!
